Envi HSL-20
SKU
SL-Envi-HSL-20
The Envi HSL-20 is an advanced slit lamp microscope designed for high performance, accurate diagnostics, reliability, and patient comfort. High-quality optics result in excellent image quality and resolution. The HSL-20 features light tower LED illumination and two-step magnification.
Technical Specifications
- Minimum slit opening: 0mm
- Slit maximum length: 14mm
- Continuously adjustable slit length: 1.8-14mm continuously variable
- Slit projection scale: 1.2x
- Slit aperture diaphragms: 0.2/1/3/5.5/9/14mm
- Filters: Clear, Blue, Natural Density, Yellow, Red-free
- Slit maximum length: 0mm
- Slit rotation: 0-180 with reference scale
- Vertical slit tilting angles: 0/5/10/15/20
- Working distance: 75mm
- Base travel: 103mm x-axis, 100mm y-axis, 35mm z-axis
- Microscope type: Convergent binocular optical microscope
- Magnification power selection: Five position rotating drum
- Eyepiece: 12.5x
- Magnifying powers: 10x, 16x
- Field of view (mm): 36, 22, 14, 9, 5.6
- Distance between pupils: 48.5 – 80mm
- Objective lens working angle: 12
Downloads Attachments
| No. | Thumbnail | File | Description |
|---|---|---|---|
| 1) |
|
envi-hsl-20.pdf | Envi HSL-20 |
