Envi ZSL-50

SKU
SL-N-Envi-ZSL-50

The Envi ZSL-50 is an advanced LED slit lamp microscope designed for high performance, accurate diagnostics, reliability, and patient comfort. High-quality optics result in excellent image quality and resolution. The ZSL-50 features 5-Step drum rotation for selecting the desired magnification setting (multi-mag).



Technical Specifications

  • Minimum slit opening: 0mm
  • Slit maximum length: 14mm
  • Continuously adjustable slit length: 1.8-14mm continuously variable
  • Slit projection scale: 1.2x
  • Slit aperture diaphragms: 0.2/1/3/5.5/9/14mm
  • Slit aperture diaphragms: 0.2/1/3/5.5/9/14mm
  • Filters: Clear, Blue, Natural Density, Yellow, Red-free
  • Slit maximum length: 0mm
  • Slit rotation: 0-180 with reference scale
  • Vertical slit tilting angles: 0/5/10/15/20
  • Working distance: 75mm
  • Base travel: 103mm x-axis, 100mm y-axis, 35mm z-axis
  • Microscope type: Convergent binocular optical microscope
  • Magnification power selection: Five position rotating drum
  • Eyepiece: 12.5x
  • Magnifying powers: 6x, 10x, 16x, 25x, 40x
  • Field of view (mm): 36, 22, 14, 9, 5.6
  • Distance between pupils: 48.5 – 80mm
  • Objective lens working angle: 12



https://envieye.com/envi-zsl-50/

No. Thumbnail File Description
1) envi-zsl-50.pdf Envi ZSL-50
