Visionix VX-90 Autorefractor/Keratometer - NEW
SKU
ARK-N-VN-VX90
Overview
Visionix VX 90
ARK with auto fog system
Visionix VX 90
ARK with auto fog system
The VX 90 is an ophthalmic diagnostic device with refraction and keratometry functionalities as well as accurate of cataracts. A moving fixation target with auto fogging allows the patient to fully desaccommodate in order to get the patient refraction in any conditions.
-
Refraction
- Measure the refraction of the eye by indicating sphere, cylinder and axis
-
Keratometry
- Measure the central and peripheral keratometry
-
Backlighting
- Be aware of the presence of cataracts by using backlighting for internal opacity detection
Features:
General
- Target Fixation: Auto fog system
- Measurement data display: 7” TFT colour LCD with touch screen (800×480)
- PD Measurement: 85 mm measuring range max, 1 mm display unit
- Measurement data recording: Built in thermal printer
- External output terminal: RS232/WIFI
- Power source, power consumption: 110V-240V AC, 50/60 Hz, 50 VA
- Standards: Compliance with Medical Device Directive 93/42/EC
MEASUREMENT Specification
- Power Range: -20 D to +20 D
- Power Accuracy: +/- 0.25 D
- Astigmatism range: 0 to 10D
- Astigmatism accuracy: 0.25 D
- Axis range: 0° to 180°
- Axis step: 1°
- Axis accuracy: +/- 5°
- Pupil diameter measured: 2,5 mm minimum
Keratometry Specifications
- Corneal radius range: 5 mm to 10 mm
- Corneal refractory power: 33D to 67D (n=1.3375)
- Power repeatability: 0.03 mm
- Corneal astigmatic power: 0 to 12 D
- Astigmatism accuracy: 0.02D
- Axis range: 0° to 180°
- Axis step: 1°
- Axis accuracy: +/- 5°
- Measurement diameter: 2 mm to 12 mm
- Peripheral keratometry: Nasal, temporal, up, down
